3M 7000031459 Vinyl Electrical Tape Super 88 1.5in X 36yd

Product Description

The 3M 7000031459 is a premium-grade, 8.5-mil thick vinyl electrical insulating tape designed for professional electrical work. Known as Scotch Super 88, this all-weather PVC-backed tape delivers primary electrical insulation for splices rated up to 600 volts and provides protective jacketing on conductors and connections. Its thicker construction allows faster insulation build-up compared to standard electrical tapes. The tape performs reliably across a wide temperature range, from 0 degrees F (-18 degrees C) in cold environments up to 220 degrees F (105 degrees C) in high-heat applications. Each roll measures 1.5 inches wide by 36 yards long.

This tape is suited for use in residential, commercial, and industrial electrical installations. Licensed electricians and electrical contractors use it for insulating wire splices, bundling conductors, and applying protective jacketing to cables exposed to harsh conditions. Its resistance to UV rays, moisture, abrasion, copper corrosion, alkalies, and acids makes it appropriate for both indoor and outdoor applications where long-term durability is required. The flexible PVC backing conforms well to irregular surfaces and irregular splice geometries encountered in field conditions.

Key Features

• 8.5-mil thickness for faster insulation build-up and enhanced mechanical protection
• Primary electrical insulation rated for splices up to 600 volts
• Excellent resistance to UV rays, moisture, abrasion, copper corrosion, alkalies, and acids
• All-weather performance rated from 0 degrees F to 220 degrees F (-18 degrees C to 105 degrees C)
• Flexible PVC backing conforms to irregular splice and conductor geometries
• UL Listed and CSA Certified for professional electrical applications

Compatibility

Designed for use as primary insulating tape for electrical splices and protective jacketing on conductors rated up to 600 volts in professional electrical installations.

Installation Notes

Installation should be performed by a qualified electrician in accordance with applicable NEC requirements. De-energize and lock out the circuit before applying tape to any splice or connection. Stretch the tape slightly during application to ensure a tight, void-free wrap, and overlap each pass by at least half the tape width. Do not use as a substitute for listed wire connectors or terminal insulation where code requires a listed device.

Technical Specifications

• Thickness: 8.5 mil
• Width: 1.5 inches
• Length: 36 yards
• Voltage Rating: 600 volts
• Temperature Range: 0 degrees F to 220 degrees F (-18 degrees C to 105 degrees C)
• Backing Material: PVC vinyl
• Weight: 0.89 pounds
• Unit of Measure: Roll
• Certifications: UL Listed, CSA Certified

Standard Information

• Brand: 3M
• Manufacturer Part Number: 7000031459
