3M 7000031346 Heavy Duty Vinyl Electrical Tape 2in X 36yd

Product Description

The 3M 7000031346 is a heavy duty vinyl electrical insulation tape engineered for applications that demand greater mechanical strength and abrasion resistance than standard-duty tapes provide. At 10 mils thick, it is among the thickest vinyl electrical tapes in the Scotch Tape 22 series. It is UL Listed for use as electrical insulation up to 600 volts and 176 degrees F (80 degrees C) and carries a UL 510 flame-retardant rating. Electricians and maintenance technicians reach for this tape when insulating splices, terminations, and cable bundles in demanding industrial or commercial environments.

This tape is suited for heavy duty electrical insulation work in both commercial and industrial settings. Common applications include insulating wire splices, wrapping cable bundles, and providing abrasion protection on conductors exposed to mechanical stress. The 2-inch width and 36-yard roll length make it a practical choice for larger insulation jobs where coverage and durability are priorities. It installs by hand with no special tools required.

Key Features

• 10-mil vinyl construction for superior mechanical strength and abrasion resistance
• UL Listed for electrical insulation up to 600 volts
• Rated for use up to 176 degrees F (80 degrees C)
• UL 510 flame-retardant rating
• 2-inch width and 36-yard length for efficient coverage on large jobs

Compatibility

Designed as a heavy duty vinyl insulation tape for general electrical insulation applications up to 600 volts, suitable for use by licensed electricians on commercial and industrial wiring systems.

Installation Notes

This tape is installed by licensed electricians in accordance with NEC requirements for insulation and splicing of conductors. De-energize and lock out the circuit before beginning any splice or termination work. Apply with consistent tension to ensure full adhesion and avoid gaps or voids in the insulation wrap. Surfaces should be clean and dry before application for best adhesion.

Technical Specifications

• Thickness: 10 mils
• Width: 2 inches
• Length: 36 yards
• Voltage Rating: 600 volts
• Temperature Rating: 176 degrees F (80 degrees C)
• Flame Rating: UL 510 Flame-Retardant
• UL Listing: UL Listed Electrical Insulation Tape
• Weight: 1.35 pounds
• Unit of Measure: Roll

Standard Information

• Brand: 3M
• Manufacturer Part Number: 7000031346
