3M 7000001568 Adhesive Transfer Tape Double Linered

Product Description

The 3M 7000001568 is a double-linered adhesive transfer tape designed for bonding metal and high surface energy (HSE) plastics in demanding industrial and graphic attachment applications. The tape uses 200MP acrylic adhesive, a widely recognized standard for structural joining and graphic mounting work. At 5 mil nominal adhesive thickness, it delivers strong shear resistance to prevent slippage and edge lifting under mechanical stress. The adhesive is temporarily repositionable, allowing accurate placement before final bond. Double 4.2 mil PCK layflat liners add dimensional stability and virtually eliminate curling, buckling, and rippling during storage, processing, and application.

This tape is suited for industrial assembly environments where reliable adhesion to metals and HSE plastics is required. Common applications include graphic attachment, general industrial joining, and component assembly lines where humidity exposure, temperature cycling, or solvent contact may be present. The transparent adhesive film allows for clean, low-visibility bonds. It performs consistently after exposure to humid environments and hot or cold temperature extremes, making it appropriate for both indoor controlled settings and less controlled processing or shipping conditions.

Key Features

• 200MP acrylic adhesive provides high shear strength for metals and HSE plastics
• 5 mil nominal adhesive thickness resists slippage and edge lifting
• Temporarily repositionable for placement accuracy and reduced rework
• Double 4.2 mil PCK layflat liners eliminate curling, buckling, and rippling
• High resistance to solvents and humidity
• Transparent adhesive film for clean, low-visibility bonds

Compatibility

Designed for bonding metal substrates and high surface energy plastics; suitable for graphic attachment and general industrial joining applications.

Installation Notes

Clean and dry all bonding surfaces thoroughly before application to ensure full adhesive contact. Peel the liner from one side, position the tape on the substrate, and press firmly before removing the second liner and mating the second surface. Allow final bond to develop at room temperature before applying load or stress. Follow applicable workplace safety guidelines when working with adhesive materials in industrial environments.

Technical Specifications

• Adhesive Type: 200MP Acrylic
• Adhesive Thickness: 5 mil nominal
• Liner Type: Double 4.2 mil PCK layflat
• Liner Weight: 58 lb. PCK
• Finish: Transparent
• Package Dimensions: 37.44 inches x 25.81 inches x 2.31 inches
• Package Weight: 50 pounds
• Unit of Measure: Box
• Minimum Order Quantity: 1
• UPC: 50021200184104

Standard Information

• Brand: 3M
• Manufacturer Part Number: 7000001568
