3M 6100423 Dbi-sala Cable Guide Stainless Steel

Product Description

The 3M 6100423 is a DBI-Sala cable guide constructed from stainless steel, designed to route and retain a vertical lifeline cable along fixed ladder rungs in fall protection systems. The guide fits rungs measuring 1-3/4 inches by 2-1/4 inches and is sold as an individual unit. At 0.5 pounds, it is a lightweight but durable hardware component intended for use by qualified fall protection installers and safety equipment technicians. Stainless steel construction provides corrosion resistance in demanding outdoor and industrial environments.

This cable guide is used in vertical cable fall protection systems mounted to fixed ladders, towers, tanks, and similar structures in both industrial and commercial settings. It channels the lifeline cable along each ladder rung, maintaining cable alignment and preventing displacement during use. Installers typically deploy multiple guides along the full height of a ladder run at each rung location.

Key Features

• Stainless steel construction for corrosion resistance in outdoor and harsh environments
• Fits 1-3/4 inch by 2-1/4 inch ladder rungs
• Lightweight at 0.5 pounds per unit
• Sold individually, allowing replacement of single damaged guides
• Designed for use within DBI-Sala vertical cable fall protection systems

Compatibility

Designed for use with DBI-Sala vertical cable fall protection systems on fixed ladders with rung dimensions of 1-3/4 inches by 2-1/4 inches. Confirm rung dimensions and system series before installation.

Installation Notes

Installation should be performed by a competent person or qualified fall protection technician in accordance with the manufacturer instructions and applicable OSHA and ANSI Z359 standards. Before servicing or replacing cable guides, ensure the lifeline system is taken out of service and the cable is properly de-tensioned. Do not modify the guide or use it outside its rated rung size range. Inspect all hardware and the lifeline cable before returning the system to service.

Technical Specifications

• Material: Stainless Steel
• Rung Size: 1-3/4 inches x 2-1/4 inches
• Weight: 0.5 pounds
• Unit of Measure: Each
• UPC: 840779082735

Standard Information

• Brand: 3M
• Manufacturer Part Number: 6100423
