3M 5776A-MT QS-III 3 Conductor Splice Kit 15 kV 4/0 AWG-500 KCMIL

Product Description

The 3M 5776A-MT QS-III Splice Kit is designed for splicing three conductor, armored or non-armored, shielded power cables. Rated for applications up to fifteen kilovolts, this splice kit can accommodate conductor sizes from four-aught American Wire Gauge to five hundred KCMIL, making it suitable for various installation conditions including direct burial and above ground applications.

• Rated for 5/8 to 15 kV applications
• Compatible with UL listed in-line compression connectors
• Includes items necessary to make one three conductor splice

Product Highlights

This kit supports quick and reliable installation while providing excellent moisture protection.

Product Information

Standard Information

• Manufacturer: 3M Electrical Products
• Catalog Number: 5776A-MT

Technical Specifications

• Voltage Rating: 15 kV
• Cable Type: Tape Shield
• Conductor Size: 4/0 AWG to 500 KCMIL
• Number of Conductors: 3
• Splice Type: Inline, QS-III
• Country of Origin: United States
• GTIN: 00054007441120
