3M 54007-06196 Ptfe Thread Sealant Tape 0.5x520 in 12-roll

Product Description

The 3M 54007-06196 is a 3 mil PTFE pipe thread sealant and lubricant tape rated for continuous service up to 500 degrees F (260 degrees C). Each roll measures 0.5 inches wide by 520 inches long, providing a reliable leak-proof seal on pipe threads across a wide range of plumbing, gas, and mechanical applications. The tape also acts as a lubricant to help prevent cross-threading during assembly. This SKU is sold as a bulk case of 12 rolls, making it practical for shops and service vehicles that go through tape volume regularly.

This PTFE thread sealant tape is suited for residential and light commercial plumbing, gas line fittings, and general mechanical pipe connections where a pressure-tight, leak-free joint is required. Licensed plumbers, pipefitters, and HVAC technicians use it on threaded fittings for water, gas, and air lines. The high-temperature rating makes it appropriate for hot water supply lines and steam-adjacent applications where standard tape would degrade prematurely.

Key Features

• PTFE construction rated to 500 degrees F for high-temperature service
• 3 mil thickness provides consistent coverage on standard pipe threads
• Dual function as both sealant and thread lubricant to reduce cross-threading
• 0.5 inch width fits standard 0.5 inch and larger threaded pipe connections
• Bulk case of 12 rolls reduces per-roll cost for high-volume service operations

Compatibility

Designed for use on standard threaded pipe fittings in plumbing, HVAC, gas, and pneumatic applications where a PTFE thread sealant tape is specified.

Installation Notes

Installation is typically performed by licensed plumbers, pipefitters, or HVAC technicians in accordance with applicable local plumbing codes and IFGC requirements. Shut off and depressurize the line before disassembling any threaded connection. Wrap the tape clockwise around male threads, starting at the first thread, overlapping each pass slightly, before making up the joint. Do not use on flared fittings or compression fittings where thread sealant tape is not appropriate.

Technical Specifications

• Tape Material: PTFE
• Thickness: 3 mil
• Width: 0.5 inches
• Length: 520 inches
• Maximum Temperature Rating: 500 degrees F (260 degrees C)
• Quantity per Case: 12 rolls
• Weight (per roll): 0.09 pounds
• UPC: 54007061960

Standard Information

• Brand: 3M
• Manufacturer Part Number: 54007-06196
