3M 054007-09210 Scotchlok 4/0 AWG Non-Insulated Seamless Barrel Compression Connector

Product Description

The 3M Scotchlok 054007-09210 is a non-insulated seamless barrel compression connector designed for use with four ought stranded copper wire. This connector enhances electrical connectivity in various applications.

• Made from seamless electrolytic copper for effective conductivity.
• Features chamfered barrel ends for easy wire insertion.
• Compatible with large gauge wire, ensuring secure connections.

Product Highlights

This compression connector is reliable and easy to use, ideal for electrical tasks requiring secure connections.

Product Information

Standard Information

• Brand: 3M
• MPN: 054007-09210

Technical Specifications

• Temperature Rating: 347 deg F
• Connector Type: Crimp
• Conductor Type: Stranded Copper
• Conductor Size: 4/0 AWG
• Material: Copper
• Finish: Tin-Plated
• Color: Purple
• Voltage Rating: 600 V
• Specifications: 1 in L Strip, 0.66 in OD
• Type: Non-Insulated Seamless Barrel
• Length: 2 in
• Vendor SKU: 054007-09210
• UPC: 054007092100
• Minimum Order Qty: 1
• UNSPSC: 39121432
• Order Interval: 1
• Standard & Approvals: LR22190 CSA Certified, RoHS 2011/65/EU Compliant, UL E23438 Listed
