3M 051128-57438 Scotchlok Disconnect Insulated Standard Female Ring Terminal Vinyl Blue

Product Description

The 3M Scotchlok Insulated Female Disconnect Terminal, part number 051128-57438, offers a dependable and efficient solution for quick wire connections. Its design focuses on ease of use and reliable performance in various electrical applications.

• Features a butted seam barrel with rolled edges for excellent wire holding strength.
• Vinyl insulation ensures safety and durability across a temperature range of -40 to 221 degrees Fahrenheit.
• The terminal's brass construction and tin plating enhance conductivity and corrosion resistance.

Product Highlights

This terminal integrates smoothly with wires of size 16 to 14 AWG and mates with a 0.11 inch wide male tab. Its blue vinyl insulated design aids in easy identification and installation.

Technical Specifications

• Type: Disconnect Insulated Standard
• Material: Vinyl, Brass
• Finish: Tin Plated
• Length: 0.73 inches
• Barrel Type: Butted Seam
• Tongue Type: Ring
• Temperature Rating: -40 to 221 degrees Fahrenheit
• Voltage Rating: 600 VAC
