3M 051128-57237 QSLV-M Low Voltage Cold Shrink Quick Insulator 1.6 in Diameter

Product Description

The 3M 051128-57237 QSLV-M low voltage cold shrink quick insulator is a solution for cable insulation in electrical applications. It includes open-ended tubular rubber sleeves with sealing mastic at each end. The insulator comes factory expanded, which allows for quick installation. Upon placement over an inline connector, it forms a water-resistant seal as the ends shrink around the connector. This mechanism ensures a tight fit and reliability. It is suitable for use with cables rated for up to 1000 volts, accommodating various connector types and sizes.

• Low voltage application up to 1000 volts
• Simple installation, requiring no tools
• Resistant to water, acids, and alkalis

Product Highlights

Designed for ease of use, the QSLV-M insulator offers effective sealing for cable splices and repairs.

Product Information

Standard Information

• Brand: 3M
• Capacity: 2 AWG - 1000 kcmil (Cu), 2 AWG - 500 kcmil (Al)

Technical Specifications

• MPN: 051128-57237
• Length: 2-1/2 in
• Minimum Diameter: 0.4 in
• Maximum Diameter: 1.6 in
• Tensile Strength: 1400 psi
• Material: EPDM Rubber
• Di-Electric Strength: 365 V/mil
• Application: For sheath repairs, dig-in repairs, insulation of secondary splices.
