Robertshaw 1951-536 Pilot Generator 36 inches Coaxial

Product Description

The Robertshaw 1951-536 Pilot Generator, 36" Coaxial, is a replacement part for heating, cooling, and air quality systems, specifically for stoves and fireplaces. This pilot generator is designed for use on self-powered gas control systems and ensures a standing pilot light is operative. It can be used to replace similar competitive devices.

• Easy burner installation with attached threaded nut
• Stainless steel outer jacket for long life and resistance to heat blistering
• Combination of copper and nickel alloys for good electrical conductivity

Product Highlights

The Robertshaw 1951-536 pilot generator is designed for use in various heating appliances and provides a reliable source of power for ignition systems.

Product Information

Standard Information

• Brand: ROBERTSHAW
• Manufacturer Part Number: 1951-536
• Country of Origin: Mexico

Technical Specifications

• Brand: Robertshaw
• MPN: 1951-536
• Item Model Number: 1951-536
• Cable Length: 36 in
• Probe Diameter: 3/8 in
• Probe Length: 2 in
• Output: 250 to 750mV
• Process Connection Type: Coaxial
• Process Connection Size: 3/8 in
• Compatible with Brand: Universal
• Compatible with Series: CP-2
• Includes: Mounting Nut
• Connection Type: Coaxial
• Product Type: Thermopile
• For Pilot System Type: Standing Pilot
• Material: Stainless Steel
• Voltage Rating: 250 - 750 mV
• Open Circuit Output: 500 - 750 mV
• Series: 1951
• Gas Type: LP/NG
