Littelfuse 35020028 3-Phase Voltage Monitor 190-240V

Product Description

The Littelfuse 35020028 is a 3-phase voltage monitor designed for monitoring and protecting three-phase electrical systems in a variety of settings, from industrial plants to data centers. Optimized for 190 to 240V applications, this robust device safeguards your equipment by continuously measuring voltage levels and detecting abnormalities.

• Provides real-time monitoring of voltage across three phases.
• Features adjustable thresholds to set specific voltage limits.
• Includes LED indicators for clear, immediate visual feedback on voltage status.

Product Highlights

Equipped with adjustable restart and trip delay settings, this monitor ensures your systems operate within safe voltage ranges, preventing potential damage and downtime.

Product Information

Standard Information

• Input Voltage: 190 to 240VAC
• Power Consumption: 5W
• Frequency: 50/60Hz

Technical Specifications

• Output Load Rating: General Purpose: 2 - 15A and 1hp at 240VAC
• Restart Delay: Adjustable from 2 to 300 seconds
• Mounting Type: #8 screws
• Operating Temperatures: -40 to 158 degrees Fahrenheit
• Dimensions: 2.93 inches height x 5.27 inches width x 2.95 inches depth
