Johnson Controls VG1845BGH943BUB Ball Valve Assembly 3 Way 3/4 in.

Product Description

The Johnson Controls VG1845BGH943BUB is a three-way ball valve assembly designed for HVAC systems. This valve has a three-quarter inch size and features a robust forged brass body alongside a stainless steel ball and blowout-proof stem. The direct mount electric actuator allows for precise control with a spring return of twenty-seven pounds-inch, operating at eighty-five to two hundred sixty-four volts AC for on/off functionality.

• Blow-out proof stem enhances safety.
• Designed for hot and chilled water systems.
• IP54 rated for protection against dust and water.

Product Highlights

This product is suitable for various HVAC applications, ensuring durability and reliability in temperature control.

Product Information

Standard Information

• Brand: Johnson Controls
• Part Number: VG1845BGH943BUB

Technical Specifications

• Housing: NEMA 2, IP54
• Service: Hot Water, Chilled Water, 50/50 Glycol Solution
• Auxiliary Switch: 1 x SPDT
• Power Consumption: 0.06 Amp Running, 0.02 Amp Holding
• Close-Off Pressure: 200 psig
• Flow Characteristic: Equal Percentage On The In-Line Port A, Linear Of The Angle Port B
• Operating Conditions: -22 F To 140 F
• Electrical Connections: 48 in. 18 AWG Appliance Cables With Integral 3/8 in. FMC Connectors
