Johnson Controls VG1845BG+923GGB Three-Way Ball Valve with Electric Actuator

Product Description

The Johnson Controls VG1845BG+923GGB three-way ball valve is engineered to regulate the flow of hot or chilled water, and in certain models, low-pressure steam. This versatility makes it an ideal choice for HVAC systems requiring reliable flow regulation.

• Compatible with Johnson Controls VA9104, M9106, M9109, and M9100 Series non-spring-return actuators.
• Optimal for on/off, floating, or proportional control applications.
• Constructed from forged brass, ensuring a high static pressure rating of 580 psig.

Product Highlights

Designed for robust performance, the VG1000 series ball valves offer quality and durability. Each valve is factory or field mountable to various actuators, showcasing a seamless integration for enhanced control systems.

Technical Specifications

• Material: Forged Brass Body
• Pressure Rating: 580 psig static
• Control Type: On/off, floating, proportional
• Compatible Actuators: VA9104, M9106, M9109, M9100, VA9203, VA9208
