Johnson Controls VG1845BG+9T4GGA Model VG1845BG Three-Way Stainless Steel Trim NPT Ball Valve with Model VA9104-GGA-3S with Non-Spring-Return Electric Actuator Without Switch

Product Description

The Johnson Controls VG1845BG+9T4GGA is a part of the VG1000 Series Ball Valves designed to manage the flow of hot or chilled water and low-pressure steam in HVAC systems. This model serves various control needs with factory or field-mounted actuators.

• Forged brass body
• 580 psig static pressure rating
• Non-spring-return electric actuator

Product Highlights

This VG1000 series valve offers durable and reliable performance in HVAC systems. It operates with on/off, floating, or proportional control, making it versatile for different system requirements.

Product Information

Standard Information

• Application: Regulates flow of water and steam in HVAC systems
• Sizes: 1/2 inch through 2 inches (DN15 through DN50)

Technical Specifications

• Static Pressure Rating: 580 psig
• Valve Material: Forged brass
• Actuator Type: Non-spring-return electric
• Compatible Actuators: VA9104, M9106, M9109, M9100 Series
• Control Types: On/off, floating, proportional
