Genteq Motors D1152 Fan Mtr SPM 1/20Hp 115V CW 1500Rpm 60Hz

Product Description

The GENTEQ MOTORS D1152 fan motor is a 1/20 HP, 115V, CW, 1500 RPM, 60Hz motor designed for air over applications. This shaded pole motor features extended studs for mounting and a flat shaft type. It is thermally protected with class B insulation and operates efficiently at 40°C ambient temperature.

• OEM Direct Replacement Motor
• Thermally Protected
• Open Air Over

Product Highlights

This GENTEQ MOTORS fan motor is suitable for various applications requiring a reliable and efficient motor with clockwise rotation.

Product Information

Standard Information

• Brand: GENTEQ MOTORS
• Manufacturer Part Number: D1152
• Country of Origin: Mexico

Technical Specifications

• MPN: D1152
• Brand: GENTEQ MOTORS
• Phase: 1
• Output HP: 1/20 Hp
• Output KW: 0.04 kW
• Voltage: 115 V
• Speed: 1500 rpm
• Service Factor: 1
• Frame: 3.3
• Enclosure: Open Air Over
• Thermal Protection: Thermally Protected
• Ambient Temperature: 40 °C
• Frequency: 60 Hz
• Current: 2.10 A
• Duty: Air Over
• Insulation Class: B
• UL: Recognized
• CSA: Y
• CE: N
• Number of Speeds: 1
• Electrical Type: Shaded Pole
• Starting Method: Across The Line
• Poles: 4
• Rotation: Clockwise Shaft End
• Mounting: Extended Studs
• Drive End Bearing: Sleeve
• Opp Drive End Bearing: Sleeve
• Frame Material: Steel
• Shaft Type: Flat
• Overall Length: 5.63 in
• Frame Length: 2.70 in
• Shaft Diameter: 0.313 in
• Shaft Extension: 2.35 in
