Nidec HD2P2E 2HP 1800 RPM 145T Frame Electric Motor 230/460V

Product Description

The Nidec HD2P2E electric motor offers robust performance for industrial tasks. Rated at 2 horsepower and 1800 RPM, it operates efficiently at 230/460 volts. It is equipped with a NEMA 145T frame, ensuring compatibility with various applications.

• 2 hp 1800 RPM motor
• 230/460 volts, three-phase
• NEMA 145T frame

Product Highlights

This motor features a TEFC enclosure, making it suitable for harsh environments. It supports both variable and constant torque applications. The motor includes a rigid base mount and a keyed shaft.

Product Information

Standard Information

• Brand: Nidec
• MPN: HD2P2E
• Horsepower: 2 hp

Technical Specifications

• Speed: 1800 RPM
• Voltage: 230/460V
• Amperage: 5.3/2.7 amps
• Enclosure: TEFC
• Frame: 145T
• Material: Cast Iron
• Bearing Type: Ball
• Insulation Class: F
