Honeywell MS7403A2030 Zelix S03 Series Spring Return Direct Coupled Actuator 24Vac/Dc 3K Ohm 2-10Vdc

Product Description

The Honeywell MS7403A2030 is part of the Zelix S03 Series, designed for reliable HVAC systems. This spring return direct coupled actuator operates on 24Vac/Dc and offers a torque of 27 lb-in. The actuator includes a 3K Ohm input for 2-10Vdc control signals.

• Spring return direct coupled actuator
• Operates on 24Vac/Dc
• 27 lb-in torque

Product Highlights

This Honeywell actuator is essential for HVAC systems, providing efficient torque and reliable control. Its spring return feature ensures fail-safe operation, making it ideal for various environments.

Product Information

Standard Information

• Brand: Honeywell
• Model: MS7403A2030
• Category: Damper Actuators
• Product Type: Actuator

Technical Specifications

• Torque: 27 lb-in
• Voltage: 24Vac/Dc
• Frequency: 50-60 Hz
• Control Signal: 2-10Vdc, 4-20 mA with 500 Ohm resistor
• Power Consumption: 7 VA
• Humidity Range: 5-95% RH
• Temperature Range: -40 to 149 degrees Fahrenheit
• Driving Time: 90 seconds nominal
• Spring Return Time: 25 seconds maximum
• Certifications: Class 2, NEMA 2
• Mounting: Direct coupled, includes bracket and self-centering shaft adapter
• Feedback Signal: 2-10Vdc
