Belimo CQKB24-LL Direct Coupled Actuator, 12 in-lb

Product Description

The Belimo CQKB24-LL is a direct coupled actuator designed for HVAC systems. This actuator provides on/off control and features electronic fail-safe mechanisms powered by a twenty-four volt AC supply. It directly connects to the valve without the need for additional tools or linkage.

• Durable construction suited for HVAC applications
• Electronic fail-safe for reliable operation
• Integrated design minimizes installation time

Product Highlights

Efficiently controls valve operations; ideal for heating and cooling applications.

Product Information

Standard Information

• Brand: Belimo
• MPN: CQKB24-LL

Technical Specifications

• Actuator Type: Electrical fail-safe
• Angle of Rotation: 90 degrees
• Control Type: On/Off
• Cv: 32
• Degree of Protection: IP40 NEMA 2
• Electrical Connection: Cable
• End Fitting: Internal thread
• Fluid: Potable water
• Pattern: 2-way
• Power Consumption (Holding): 0.5 W
• Power Consumption (Running): 2.5 W
• Pressure Independent: No
• Product Type: Combo
• Running Time (Fail-safe): Less than 60 seconds
• Running Time (Motor): 75 seconds at 90 degrees
• Valve Size: 0.5 inches
• Voltage AC/DC: AC/DC 24 V
