Belimo ARX24-SR-TN4 Valve Actuator Non-Spg 24V Modulating NEMA 4

Product Description

The Belimo ARX24-SR-TN4 Valve Actuator operates with non-spring return functionality. It is designed for 24V applications and offers modulating control. This actuator is enclosed in a NEMA 4 housing to provide robust protection.

• Non-spring return
• Modulating control
• NEMA 4 enclosure

Product Highlights

Ideal for HVAC applications, the Belimo ARX24-SR-TN4 ensures precise control of valves. It is suitable for use with chilled or hot water containing up to 60% glycol.

Product Information

Standard Information

• Brand: Belimo
• MPN: ARX24-SR-TN4

Technical Specifications

• Angle of Rotation: 90
• Controllable Flow Range: 75B0
• Cv: 25
• End Fitting: Internal thread
• Fluid: Chilled or hot water up to 60% glycol
• Pattern: 2-way
• Pressure Independent: NO
• Trim: Stainless steel
• Valve Size: 1.25 [32]
• Actuator Type: Non fail-safe
• Control Type: DC 2...10 V
• Degree of Protection: IP66/67 NEMA 4X UL Enclosure Type 4X
• Electrical Connection: Terminals
• Manual Override: Under cover
• Power Consumption (Holding): 0.4 W
• Power Consumption (Running): 2.5 W
• Running Time (Motor): 90 s / 90B0
• Voltage AC/DC: AC/DC 24V
