White Rodgers 36C53-418 Gas Valve 24V 3/4 x 3/4 Standing Pilot

Product Description

The White Rodgers 36C53-418 is a gas valve designed for 24V systems, featuring a nominal size of three-quarters by three-quarters inches. This standing pilot gas valve is suitable for regulating gas flow in both residential and commercial applications.

• Designed for 24VAC operation
• Includes reducer bushings and blocking pin LP kit
• Provides safe ignition with thermocouple actuation

Product Highlights

This gas valve provides precise control of gas flow, ensuring the efficient operation of gas-fired equipment. It features E.C.O. terminals with jumper lead for secure connections and a slow-opening design that aids in reducing ignition surges.

Product Information

Standard Information

• Brand: White Rodgers
• MPN: 36C53-418

Technical Specifications

• Coil Voltage: 24 VAC
• Gas Type: Liquid Propane/Natural Gas
• Nominal Capacity: 280000 Btu/cu-ft
• Pressure Rating: 0.5 psi
• Temperature Rating: -40 to 175 deg F
• End Style: 1/4 inch Compression
• Connection Size: 3/4 inch
• Ignition Type: Standing Pilot
