Honeywell M847A1072 Electric Actuator 2-Position SPST 45 deg Rotation

Product Description

The Honeywell M847A1072 is an electric actuator designed for HVAC applications. It provides a control signal for 2-position operation with a spring return feature. This actuator allows for a rotation angle of forty-five degrees, making it suitable for controlling dampers effectively. It has a torque rating of 1.9 inch-lb and operates at twenty-four volts.

• Low voltage spring return damper actuator
• Includes a mounting bracket for wall duct or direct appliance installation
• Actuator wheel rotates clockwise when energized

Product Highlights

This actuator is ideal for controlling draft dampers through an actuator arm or chain linkage. It is built for reliability and effective performance in various HVAC applications.

Product Information

Standard Information

• Manufacturer: Honeywell
• MPN: M847A1072

Technical Specifications

• Series: M847A
• Timing: 20 sec
• Dimensions: 3.5 inches H x 2.625 inches W x 3.3125 inches D
• Motor Type: Round
• Torque Rating: 1.9 inch-lb
• Control Signal: 2-Position, SPST
• Fail Safe Mode: Spring Return
• Rotation Angle: 45 deg
• Voltage Rating: 24 V
• Temperature Rating: 40 - 125 deg F
