Johnson Controls VG1845FT Ball Valve 73.7 Cv 2 NPT 3-Way

Product Description

The Johnson Controls VG1845FT is a three-way ball valve designed for HVAC applications. It features a two-inch size and a flow capacity of 73.7 Cv. This valve is suitable for regulating hot and chilled water as well as low-pressure steam. It is made with a forged brass body and a stainless steel ball, ensuring durability and reliability in various conditions.

• Maintenance-free design for prolonged use
• Constructed to handle over 200,000 cycles in contaminated water
• 500:1 rangeability for accurate control

Product Highlights

This valve is ideal for HVAC systems that require reliable and effective flow control. Its robust design makes it suitable for hot water, chilled water, and steam applications.

Product Information

Standard Information

• Service: Hot Water, Chilled Water, Glycol Solutions, Saturated Steam
• Close-Off Pressure: 200 psig
• Operating Conditions: -22 F to 280 F

Technical Specifications

• Flow Characteristic: Equal Percentage and Linear
• Material: Brass, Stainless Steel
• Body Pattern: 3-Way
• Connection Type: Threaded NPT
• Fluid Temperature Range: -22° to 284° F
• Weight: 0.1 lbs
• Shipping Dimensions: 3 x 2 x 2 inches
