Johnson Controls VG1245FSH938BGC Two-Way Stainless Steel Trim NPT Ball Valve with Electric Actuator

Product Description

The Johnson Controls VG1245FSH938BGC is a versatile two-way stainless steel trim NPT ball valve, equipped with a VA9208-BGC-3 thermal barrier open spring-return electric actuator. This valve is specifically designed for HVAC systems, supporting on/off, floating, or proportional control.

• Regulates flow of hot or chilled water and low-pressure steam.
• Compatible with VA9104, M9106, M9109, and M9100 series non-spring-return electric actuators.
• Sizes ranging from 1/2 through 2 inches.

Product Highlights

Constructed to meet the rigorous demands of controlled environments, this valve features a forged brass body with a high static pressure rating of 580 psig. Its overbuilt components ensure durability and reliable operation under varying conditions.

Product Information

Standard Information

• Manufacturer: Johnson Controls, Inc
• Material: Forged Brass

Technical Specifications

• Type: Two-way ball valve
• Actuator Model: VA9208-BGC-3
• Size Range: 1/2 to 2 inches
• Pressure Rating: 580 psig
