Product Description
The Siemens 268-03008 model is a 2-inch 2-way normally open stainless steel globe valve actuator combo, designed for robust performance in HVAC systems. Ideal for handling hot or chilled water, 50% water-glycol solutions, and steam applications. This valve ensures reliable flow control with features tailored for easy integration into existing setups.
- Durable stainless steel construction ensures long service life and resistance to corrosive media.
- Features ANSI Leakage Class IV for precise flow control with less than 0.01% of Cv leakage.
- Equipped with a 4-inch pneumatic actuator adjustable from 3 to 8 psi, suitable for various operational pressures.
Product Highlights
Ensures compliance with ANSI 250 standards, integrating easily into both commercial and industrial environments. The universal bonnet design supports direct coupling with actuators, promoting easier installation and maintenance.
Product Information
Standard Information
-
Connection Type: Female x Female
-
Body Pattern: 2-Way
Technical Specifications
-
Material: Stainless Steel
-
Actuator Size: 4-inch with 3-8 psi adjustment range
-
Flow Capacity (Cv): 40.0
-
Connection Size: 2 inches
