Eaton PKZM0-1.6 Manual Motor Protector Circuit Breaker 16A

Product Description

The Eaton PKZM0-1.6 Manual Motor Protector Circuit Breaker is designed for motor protection with a current rating of 16A. This device belongs to the XT Series, featuring a 3-pole configuration and is suitable for use in commercial and institutional buildings.

• Push button actuator
• Screw connection
• DIN Rail mounting

Product Highlights

The Eaton PKZM0-1.6 Circuit Breaker offers reliable motor protection for various applications. It is built to meet UL 489 standards and features a 45 mm frame with Class 10 trip. This device ensures safety and efficiency in motor control systems.

Product Information

Standard Information

• Brand: Eaton
• MPN: PKZM0-1.6
• Manufacturer: Eaton
• Application: Motor and Power Control Equipment

Technical Specifications

• Actuator Type: Push Button
• Amperage Rating: 25 A
• Application: Motor and Power Control Equipment Applications
• Connection Type: Screw
• Dimensions: 1.8 in L x 3 in W x 3.7 in H
• Enclosure: IP20
• Frame: 45 mm
• Number of Poles: 3
• Power Rating: 7.5 kW
• Standards/Approvals: UL 489
• Temperature Rating: -25 to 55 deg C
• Trip Type: Class 10
• Voltage Rating: 690 VAC
