Honeywell T678A1155 Remote Bulb Commercial Temperature Controller 120/240/277 Vac

Product Description

The Honeywell T678A1155 Remote Bulb Commercial Temperature Controller is engineered to regulate temperature efficiently in various applications, including ducts, pipes, tanks, and boilers. This robust device operates between 5 degrees Fahrenheit to 95 degrees Fahrenheit and features a responsive copper bulb sensing element.

• Operates with 2 SPDT output for versatile control functionality.
• Equipped with a long, 5-foot capillary for extended reach.
• Supports both 120 Vac and 240/277 Vac, making it adaptable to various installations.

Product Highlights

Designed for precise temperature regulation, Honeywell's T678A1155 model is suitable for both heating and cooling systems. It can be mounted in any position, offering flexibility during installation. The controller's rapid response model significantly enhances operational efficiency, being about four times faster than standard models.

Technical Specifications

• Application: Temperature control in air or liquid systems
• Output Type: Relay
• Type: Remote Bulb
• Voltage: 120 Vac or 240/277 Vac
• Frequency: 50 Hz, 60 Hz
• Sensor Element: Copper bulb
• Number of Sensor Inputs: 1
• Maximum Connected Load: 2000 VA
