Johnson Controls VG1245CL+923GGB Two-Way Stainless Steel Valve NPT Connection Ball Valve with Electric Actuator Switch

Product Description

Johnson Controls model VG1245CL+923GGB features a two-way stainless steel trim NPT end connection ball valve coupled with a VA9203-GGB-2Z open spring-return electric actuator, designed for robust control of HVAC systems. This product facilitates efficient regulation of hot or chilled water flow and, in certain models, low-pressure steam.

• Durable forged brass body with a high static pressure rating of 580 psig
• Includes auxiliary switch and positional feedback for precise control
• Equipped with an electrical connection featuring a 48-inch long 18 AWG appliance cable

Product Highlights

This valve assembly is optimal for on/off, floating, or proportional control within HVAC systems. It supports 24 VAC/VDC power requirements and offers a close-off pressure of 200 PSID.

Product Information

Standard Information

• Manufacturer: Johnson Controls, Inc.
• Product Type: Valve

Technical Specifications

• Connection Type: Threaded
• Material: Stainless Steel
• Actuator Type: Proportional with 500 ohm resistor
• Fail Safe Mode: Port A open, spring return
• Fluid Temperature Range: -22 to 212 degrees Fahrenheit
• Flow Capacity (Cv): 7.4
