Siemens 241-00213 1 NPT 2-Way Normally Open Zone Valve SR Fail Safe Actuator 7.0 Cv 120V

Product Description

The Siemens 241-00213 is a 1 inch NPT, 2-way, normally open zone valve designed for HVAC systems. It operates at 120 volts and features a 7.0 Cv rating. This valve includes a fail-safe actuator, making it ideal for controlling baseboard radiation and terminal fan coil units.

• 2-way valve pattern
• 7 Cv flow capacity
• 120V operation

Product Highlights

This Siemens zone valve is built for controlling HVAC systems with reliability and precision. The fail-safe actuator ensures dependable operation, while the 1 inch NPT connection provides compatibility with standard piping configurations.

Product Information

Standard Information

• Brand: Siemens
• MPN: 241-00213

Technical Specifications

• Valve Size: 1 inch
• Connection Type: NPT
• Pressure Rating: 125 psi WOG
• Body Material: Brass
• Flow Capacity (Cv): 7.0
• Max Temperature: 230 degrees Fahrenheit
• Valve Pattern: 2-way
• Voltage: 120V
• Position: Normally Open
