Johnson Controls VG7243ET+7153G Stainless Steel Trim Globe Valve Electric Actuator

Product Description

The Johnson Controls VG7243ET+7153G Stainless Steel Trim Globe Valve comes with the VA-7153-1001 Non-Spring Return Electric Actuator. This valve is designed to control hot or chilled water or steam. It fits VG7000 Series valves with sizes ranging from 1/2 inch to 2 inches. The body has a static pressure rating of ANSI Class 250 and can be assembled in the factory or the field. It operates on 24 VAC at 50/60 Hz and uses 4.7 VA.

• Tight close-off with 90 lb. force

Product Highlights

This valve is compatible with hot or chilled water systems and steam applications. It is ideal for controlling fluid flow in HVAC systems.

Product Information

Standard Information

• Manufacturer: Johnson Controls, Inc
• Brand: Johnson Controls

Technical Specifications

• Valve Body Static Pressure Rating: ANSI Class 250
• Voltage: 24 VAC, 50/60 Hz
• Power Consumption: 4.7 VA
• Force Output: 90 lb.
• Valve Size Compatibility: 1/2 inch to 2 inches
