Johnson Controls VG7243CT+3008B Stainless Steel Trim Globe Valve 3-6 psig Spring Range

Product Description

The Johnson Controls VG7243CT+3008B Stainless Steel Trim Globe Valve is designed to control the flow of hot or chilled water and 100 psig saturated steam. This valve assembly features a 1/2 inch Npt connection and a normally open (N.O.) configuration, providing secure and versatile mounting. The durable construction ensures long-lasting performance, while the 3008B actuator offers precise valve control.

• 1/2 inch Npt connection for secure and versatile mounting
• Normally open configuration for fail-safe operation
• Efficient flow control with a Cv value of 73

Product Highlights

Features a rugged actuator die-cast enclosure that fits VG7000 valves 1/2 inch through 1-1/4 inch. Built for industrial applications, this valve assembly is ideal for manufacturing lines, chemical and petrochemical industries, and more.

Product Information

Standard Information

• Brand: Johnson Controls
• Item Number: VG7243CT+3008B

Technical Specifications

• Maximum supply air pressure: 25 psig (172 kPa)
• Fluid temperature range: 35 to 338 degrees Fahrenheit (2 to 170 degrees Celsius)
• Valve body static pressure rating: ANSI Class 250
• Spring range: 3 to 6 psig
• Actuator: Model V-3000-8012
• Connection: 1/2 inch Npt
• Cv value: 73
