Johnson Controls VG1841AD+923BGA Brass Valve Assembly

Product Description

Johnson Controls model VG1841AD+923BGA features a three-way brass valve assembly, precisely engineered to control hot, chilled water flow and low-pressure steam in HVAC systems. This valve assembly is universally compatible with a range of Johnson Controls non-spring return and spring return actuators including models from VA9104, M9106, M9109, M9100 series (non-spring return) and VA9203, VA9208 series (spring return).

• Optimal for sizes ranging from 1/2 inch to 2 inches (DN15 to DN50).
• Factory or field-installable for flexible installation.

Product Highlights

This assembly can manage on/off, floating, or proportional control setups, responding efficiently to controller commands.

Product Information

Standard Information

• Body Material: Brass
• Control Type: On/Off, Floating, Proportional

Technical Specifications

• Pressure Rating: 580 psig static
• Connection Type: Threaded
• Electrical Requirements: 24 VAC +/- 20%, VDC +/- 10%
• Compatible Actuators: VA9104, M9106, M9109, M9100, VA9203, VA9208
