Johnson Controls VG1245DR+948AGA Two-Way Stainless Steel Valve 24V 1-1/4 NPT

Product Description

The Johnson Controls VG1245DR+948AGA is a two-way stainless steel valve designed for HVAC systems. This valve regulates the flow of hot or chilled water and low-pressure steam in response to a controller. It includes the VA9208 actuator for precise on/off and floating point control.

• Forged brass body with 580 psig static pressure rating
• Available in sizes 1/2 inch to 2 inches (DN15 to DN50)
• Field mounted to non-spring-return and spring-return electric actuators

Product Highlights

Ideal for HVAC systems, the VG1245DR+948AGA controls water and steam flow efficiently. It is equipped with a VA9208 actuator for accurate performance.

Product Information

Standard Information

• Brand: Johnson Controls
• MPN: VG1245DR+948AGA

Technical Specifications

• Manufactured By: Johnson Controls
• Flow Capacity (Cv): 29.2
• Power Requirements: 24 VAC +/- 20%, VDC +/- 10%
• Electrical Connections: 120 inches (3.05 m) 19 AWG Plenum Cable
• Close Off Pressure: 200 PSID
• Valve Material: Stainless Steel
• Actuator Type: Floating Point, On/Off
• Fail Safe Mode: Spring Return, Port A Closed
• Connection Type: Threaded
• Fluid Temperature Range: -22 to 212 degrees Fahrenheit
• Body Pattern: 2-Way
• Weight: 5 lbs
• Shipping Dimensions: 5 x 5 x 3 inches
• Features: Weather Shield Options for Field Assembly
