Johnson Controls VG1245DR+938BGA Model VG1245DR Two-Way Stainless Steel Trim NPT End Connection Ball Valve with Model VA9208-BGA-3 Open Non-Spring-Return Electric Actuator Without Switch

Product Description

The Johnson Controls VG1245DR+938BGA is a two-way stainless steel trim NPT end connection ball valve equipped with a VA9208-BGA-3 open non-spring-return electric actuator. This model is part of the VG1000 Series Ball Valves, designed to regulate the flow of water and low-pressure steam in HVAC systems.

• Flow capacity of 29.2 Cv
• Static pressure rating of 580 psig
• Factory or field mounted to Johnson Controls actuators

Product Highlights

This valve is ideal for managing hot or chilled water and low-pressure steam, making it suitable for HVAC applications. It provides reliable on/off, floating, or proportional control.

Product Information

Standard Information

• Brand: Johnson Controls
• MPN: VG1245DR+938BGA

Technical Specifications

• Flow Capacity (Cv): 29.2
• Static Pressure Rating: 580 psig
• Power Requirements: 24 VAC +/- 20%, VDC +/- 10%
• Electrical Connections: 48 inches 18 AWG Appliance Cable
• Close Off Pressure: 200 PSID
• Actuator Type: 24V, On/Off
• Fail Safe Mode: Port A Open, Spring Return
• Connection Type: Threaded
• Material: Stainless Steel
• Body Pattern: 2-Way
• Fluid Temperature Range: -22 to 212 degrees Fahrenheit
