Johnson Controls VG1245DR+938BAA Two-Way Stainless Steel Valve with Electric Actuator

Product Description

The Johnson Controls VG1245DR+938BAA Ball Valve is crafted to manage the flow of hot or chilled water and low-pressure steam in HVAC systems. This reliable model is compatible with Johnson Controls non-spring and spring-return electric actuators for versatile control options.

• Durable forged brass body with a high static pressure rating of 580 psig.
• Designed for sizes 1/2 inch to 2 inches, accommodating various piping requirements.
• Seamless integration with existing Johnson Controls electric actuators.

Product Highlights

Offering a flow capacity of 29.2 Cv, this valve ensures efficient fluid handling within a building's climate control systems. It operates effectively within a fluid temperature range of -22 to 212 degrees Fahrenheit, making it suitable for diverse operating environments.

Technical Specifications

• Power Requirements: 120 VAC at 60 Hz, allowing stable operation.
• Electrical Connections: 48 inches appliance cable.
• Maximum Close Off Pressure: 200 PSID, ensuring robust performance under high-pressure conditions.
• Body Material: Stainless Steel, offering excellent corrosion resistance.
• Actuator Type: 120V on/off, providing precise control.
• Connection Type: Threaded connections for secure installation.
• Valve Type: Two-way body pattern.
