York S1-01504788004 Scroll Compressor 25000 Btu/hr R-410A

Product Description

The York S1-01504788004 is designed as a fixed capacity scroll compressor. This compressor is suitable for residential applications and provides up to 25000 Btu/hr cooling capacity. It functions at a voltage of 208/230 VAC and uses R-410A refrigerant.

• High efficiency with up to 10.45 EER
• Built on a proven platform with excellent reliability
• Designed for high temperature and ultra high pressure conditions

Product Highlights

This compressor is ideal for residential air conditioning systems, ensuring reliable performance for home cooling needs.

Product Information

Standard Information

• Brand: York
• Part Number: S1-01504788004

Technical Specifications

• Amperage Rating: 15 A Rated Load, 72.5 Locked Rotor
• BTU Rating: 25000 Btu/hr
• Connection Type: Stub, 1/2 in Discharge x 3/4 in Suction
• EER: Up to 10.45
• Frequency Rating: 60 Hz
• HP Rating: 1 - 5 hp
• Item Name: Scroll Compressor
• Mass Flow: 419/370 lb/hr
• Oil Type: 3MA Polyol Ester (POE)
• Phase: 1 ph
• RPM: 3500 rpm
• Refrigerant: R-410A
• Tonnage: 2 ton
• Voltage Rating: 208/230 VAC
