Product Description
The York S1-01504615004 is a scroll compressor designed for residential use. This model provides a cooling capacity of 51000 Btu/hr and operates at 208/230 VAC with R-410A refrigerant. It uses a fixed-speed design with improvements that meet current efficiency standards.
- 6th generation fixed-speed compressor
- Built upon the proven ZPK5 platform
- Capacitor run for reliable operation
Product Highlights
This compressor is built for efficiency and reliability, featuring internal protection and support for high temperature and pressure applications.
Product Information
Standard Information
-
Manufacturer: York
-
Part Number: S1-01504615004
Technical Specifications
-
BTU Rating: 51000 Btu/hr
-
Amperage Rating: 144.2 A Locked Rotor, 38 A Maximum Continuous
-
Voltage Rating: 208/230 VAC
-
Frequency Rating: 60 Hz
-
HP Rating: 1 - 5 hp
-
Connection Type: 1/2 in Discharge x 7/8 in Suction
-
Refrigerant: R-410A
-
Mass Flow: 745/840 lb/hr
-
Oil Type: 3MA Polyol Ester (POE)
-
Phase: 1 ph
-
RPM: 3500 rpm
-
EER: Up to 10.65
