York CF64DXA1 Add-On Indoor Coil 5 Ton

Product Description

The York CF64DXA1 is an add-on indoor coil designed for upflow and downflow configurations. It is a full-cased model that can handle a nominal capacity of five tons, suitable for use with UPG furnaces and modular air handlers. This coil ensures efficient heat exchange, allowing for rapid airflow to reach desired temperature set points while effectively managing moisture removal.

• MaxAlloy aluminum construction for enhanced durability.
• Compact design simplifies installation, even in tight spaces.
• Factory-tested for leak protection and reliability.

Product Highlights

The York CF64DXA1 coil is built for long-term performance and energy-efficient operation with heat pump systems.

Product Information

Standard Information

• Brand: York
• Model: CF64D

Technical Specifications

• Air Flow Direction: Upflow/Downflow
• CFM Rating: 1800 cfm
• Coil Rating: 9.98 sq-ft Face Area, 2 Rows, 14 fins/in
• Coil Size: (3) 28 x 17.1 in
• Connection Type: 3/8 in Sweat Liquid, 7/8 in Sweat Vapor
• Dimensions: 24-1/2 in W x 32-3/4 in H x 21-1/2 in D
• Material: Steel
• Finish: Galvanized
• Refrigerant: R-410A, R-22
• Nominal Capacity: 5 ton
• Standards/Certifications: cCSAus, AHRI certified, ISO 9001 standard
