WINCO 99840-005 PTO Generator - 15kW, 120/240V, 1-PH, 515 RPM

Product Description

The WINCO W15PTOS 99840-005 is a PTO generator tailored for farm, agricultural, and home applications. This unit delivers a starting capacity of fifteen thousand watts. It operates on a single-phase voltage of 120/240V and features a gearcase running at five hundred fifteen RPM. The generator is equipped with a sixty Amp NEMA 14-60 full power plug. It is designed to be powered by a thirty horsepower tractor engine and connects using a one and three-eighth inches six splined input shaft.

• Single phase 120/240V output
• Requires thirty HP tractor engine and five hundred fifteen RPM PTO input speed
• Includes a sixty Amp NEMA 14-60 full power plug

Product Highlights

This PTO generator supports various applications with its robust design and powerful output.

Product Information

Standard Information

• Manufacturer: Winco
• MPN: 99840-005

Technical Specifications

• Model Number: 99840-005
• Item Type: PTO Generator
• Generator Grade: Commercial, Industrial, Professional, Semi-Professional
• Generator Style: PTO Generator
• Phase: Single-Phase
• Frequency: 60 Hz
• Voltage: 120/240V
• Standby Watts: 15000
• Continuous Watts: 13000
• Running Watts: 15000
• Standby Amps | 1.0 PF: 62.5
• Continuous Amps | 1.0 PF: 54
• Rated Amps @ Max Volt: 62.5
• PTO Input Speed: 515 RPM
• Tractor HP Required: 30
• Motor Starting HP Rating: 7.5
• Poles: 2
• Alternator: Brushless
• Voltage Regulation: +/- 5%
• Total Harmonic Distortion: Less Than 5%
• Circuit Breakers: 60 Amp
• Generator To Drive Shaft Connection: 1 3/8 Inch 6 Splined Input Shaft
• Control Panel Display: Yes, Voltmeter
• Unit Dimensions: 33.0L x 19.0W x 20.0H
• Weight (Lbs.): 232
• Assembled In: USA
