Product Description

The Weil-McLain 623900103 is a left-hand cast iron baseboard radiator section measuring two feet. It is designed for use in hydronic heating systems. This section includes a footed end cap and a closed connection port. Made from durable cast iron, it offers effective heat distribution for both residential and commercial applications. The baseboard radiator is compatible with standard one-and-one-fourth inch Baseray push nipple connections.

• Constructed from cast iron for effective heat retention
• Designed as a left-end termination for hydronic systems
• Compatible with hot water and steam heating applications

Product Highlights

This baseboard section is essential for extending hydronic systems and maintaining thermal efficiency in heating setups.

Product Information

Standard Information

• Brand: Weil-McLain
• Manufacturer Part Number: 623900103

Technical Specifications

• Model Number: 623-900-103
• Material: Cast Iron
• Length: 24 inches
• Height: 9.75 inches
• Connection Type: Female NPT
• Connection Size: 3/4 inches
• Application: Hot water and steam hydronic heating systems
• Product Type: Left Hand Sub Assembly
• Configuration: Left-end section with molded foot and sealed port
• Connection: 1-1/4 NPT push nipple (Baseray connection system)
• Width: 2.25 inches
• Product Family: Hydronic Equipment
• BTU at 180 Fahrenheit: 1140
