WAGO 221-615 Splicing Connector with Operating Lever 600 VAC 30 A 15 Piece Box

Product Description

The WAGO 221-615 is a splicing connector designed for efficient electrical connections. This connector supports wire sizes from twenty to ten AWG and operates at a voltage rating of six hundred VAC with a maximum current of thirty Amps. It comes in a pack of fifteen and features a user-friendly lever for easy termination.

• Allows solid, stranded, and fine-stranded conductors
• Compact design for space savings
• UL approved for safety

Product Highlights

This splicing connector is ideal for both installers and manufacturers. The lever mechanism simplifies the connection process by allowing quick conductor insertion and termination.

Product Information

Standard Information

• Manufacturer: WAGO Corporation
• Quantity in Box: fifteen

Technical Specifications

• MPN: 221-615
• Wire Size: 10 AWG
• Voltage Rating: 600 VAC
• Amperage Rating: 30 A
• Number of Poles: 5
• Wire Strip Length: 0.47 to 0.55 inches
• Temperature Rating: 85 degrees C
• Dimensions: 1.445 inches Width x 0.398 inches Height x 0.831 inches Depth
