US Aluminum CAPFA2422B3 2.0 Ton Upflow/Downflow Cased A Coil

Product Description

The US Aluminum CAPFA2422B3 is a cased A coil suitable for both upflow and downflow applications. This evaporator coil is designed for use with air conditioners or heat pump systems. Its all-aluminum construction promotes durability and effective heat transfer. The coil has undergone pressure testing and is compatible with R-32 refrigerant.

• Cased A coil design.
• Suitable for upflow or downflow configurations.
• Constructed with aluminum.

Product Highlights

The US Aluminum CAPFA2422B3 features a robust design ideal for residential and commercial HVAC systems.

Product Information

Standard Information

• Product Line: CAPFA
• Product Category: Evaporator Coil

Technical Specifications

• Refrigerant Type: R-32
• Casing: Cased
• Style: A Coil
• Configuration: Upflow/Downflow
• Capacity: 2.0 Tons
• Cooling BTU: 24000
• Suction Connection Size: 3/4 Inch
• Liquid Connection Size: 3/8 Inch
• Cabinet Width: 17.5 Inches
• Product Height: 22 Inches
• Product Width: 17.5 Inches
• Product Depth: 21 Inches
• Product Weight: 27 Pounds
• Shipping Weight: 42 Pounds
• ETL Listed: Yes
• AHRI Certified: Yes
• ISO Certified: Yes
• Parts Warranty: 10 Limited Years
• TXV Installed: No
• UPC: 663051696211
