US Aluminum AHVE36CP1300 Air Handler 3.0 Ton Horizontal-Discharge

Product Description

The US Aluminum AHVE36CP1300 air handler features a capacity of three tons and operates in a horizontal configuration. It is designed to provide effective air distribution and includes an all-aluminum evaporator coil, which maximizes heat transfer. The unit is equipped with a thermoplastic drain pan and a variable-speed ECM blower motor for enhanced performance.

• Integrated internal electronic expansion valve (EEV)
• Variable-speed ECM blower motor for efficiency
• Optimized for use with R-32 refrigerant

Product Highlights

This air handler offers robust performance with an emphasis on energy efficiency.

Product Information

Standard Information

• Brand: US Aluminum
• MPN: AHVE36CP1300

Technical Specifications

• Product Line: AHVE
• Tonnage: 3.0 Tons
• Cooling BTU: 36000
• Configuration: Horizontal
• Refrigerant Type: R-32
• Installation Location: Indoor
• Blower Motor Type: ECM Variable-Speed
• Maximum Air Flow: 1260 CFM
• Minimum Air Flow: 800 CFM
• Input Voltage: 208/230 Volts
• Phase: 1
• Frequency: 60 Hz
• Minimum Circuit Ampacity: 6.5 Amps
• Recommended Breaker Size: 15 Amps
• Suction Connection Size: 7/8 Inch
• Liquid Connection Size: 3/8 Inch
• Drain Outlet Diameter: 3/4 Inch
• Cabinet Width: 21 Inches
• Product Height: 53 7/16 Inches
• Product Width: 21 Inches
• Product Depth: 21 Inches
• Product Weight: 125 Pounds
• Electric Heat: Available
• TXV Installed: Yes
• Certifications: AHRI certified; ETL listed
• Parts Warranty: 10 Limited Years
• Evaporator Coil Tube Size: 7mm
• Smart Thermostat Compatibility: Compatible with Goodman brand smart thermostat
• Compliance: UL 60335 2-40 Compliant
• Cabinet Air Leakage at 1.0 inch H2O: less than 2.0% when tested in accordance with ASHRAE standard 193
• Cabinet Air Leakage at 0.5 inch H2O: less than 1.4% when tested in accordance with ASHRAE standard 193
• Electric Heater Kit: Field Installed 3kW-25kW electric heater kit available
• Filter Access: Tool-less filter access
