Uponor A2670501 5 Loop Manifold Assembly 15.4 GPM (1-1/4 X 3/4 IN) Replacement MPN A2670501

Product Description

The Uponor A2670501 is a 5 loop manifold assembly designed for hydronic radiant heating systems. This engineered polymer manifold features isolation and balancing valves with built-in flow meters, making it ready for installation. Its configuration allows a maximum flow rate of 15.4 GPM. The manifold connects with ISO 228-G threads and is compatible with R32 and R20 connections.

• Engineered polymer construction for durability.
• Fully assembled with isolation and balancing valves.
• Five-loop configuration for flexible hydronic systems.

Product Highlights

This product is suitable for radiant heating and cooling applications. It features a modular design allowing for easy expansion.

Product Information

Standard Information

• Manufacturer: Uponor
• MPN: A2670501

Technical Specifications

• Item Name: EP Heating Manifold Assembly With Flow Meter
• Nominal Size: 1-1/4 X 3/4 IN
• Connection Type: ISO 228-G X ISO 228-G
• Number Of Loops: 5
• Flow Rate: 15.4 GPM
• Width: 15.786 IN
• Height: 14.184 IN
• Depth: 3.11 IN
• Body Material: Engineered Polymer
• Loop Cv: 1.4
• Manifold Insert Material: PA66-GF30
• Test Pressure Max (Air): 101.5 PSI
• Test Pressure Max (Water): 145 PSI
