Honeywell MS7505W2030 Floating Spring Return Direct Coupled Actuator 44 lb-in

Product Description

Honeywell's MS7505W2030 is a robust floating spring return direct coupled actuator designed for precision control of air dampers, air handlers, and other HVAC applications. This product integrates seamlessly with systems requiring floating or modulating input signals ranging from 0 to 10 Vdc and provides tangible enhancements in efficiency and reliability.

• 44 lb-in torque for powerful operation.
• Spring return function ensures failsafe operation in the absence of power.
• Compatible with a variety of shaft sizes due to the inclusion of a self-centering shaft adapter.

Product Highlights

The MS7505W2030 features brushless DC submotor technology equipped with electronic stall protection, preserving motor integrity during high torque scenarios. This unit is built to withstand demanding environments, evidenced by its UL (cUL) listing and CE compliance. Practical features like built-in mechanical end limits and a field-selectable spring return direction facilitate versatile deployment and operation.

Product Information

Technical Specifications

• Control Signal Capabilities: Floating or Modulating (0/2-10 Vdc)
• Torque: 44 lb-in (5 Nm)
• Spring Return: Yes
• Dimensions: 10.5 x 5 x 4.4 inches
• Weight: 4 pounds
• Operating Voltage: 24 Vac/dc
• Ambient Temperature Range: -40 Degrees to 149 Degrees F
