Sioux 250-696122P TurboVent Air Admittance Valve 1-1/2 x 2 in SCH 40

Product Description

The Sioux Chief 250-696122P TurboVent is an air admittance valve suitable for use as a vent terminal in plumbing systems. It connects seamlessly to the DWV system through a Schedule 40 adapter.

• Features a self-cleaning actuating device that spins when activated.
• Maintains a positive seal at back pressure up to 13 PSIG.
• Includes OxBox kit with frame, louvered cover, and PVC hub adapter.

Product Highlights

This valve is effective for preventing sewer gases from entering occupied spaces and is essential for ensuring proper ventilation in plumbing installations.

Product Information

Standard Information

• Brand: Sioux Chief
• Manufacturer Part Number: 250-696122P

Technical Specifications

• Body Material: PVC
• Connection Size: 1-1/2 x 2 inches
• Inlet Size: 1-1/2 to 2 inches
• Media Handled: Air
• Pressure Rating: 13 PSIG
• Schedule Rating: SCH 40
• Applicable Standard: ANSI/NSF 14, ASSE 1050/1051, UPC, IAPMO, IPC
• Application: Suitable for wood or metal stud construction
• End Style: Hub
• Softgoods Material: Elastomer
• Dimensions: 2-11/16 inches diameter x 2-1/8 inches height
• Nominal Size: 1-1/2 x 2 inches
• Material: ABS
• Standards/Approvals: ASSE 1050/1051 Certified, ASTM D2661/D2665/F409 Specified, IAPMO Approved
