Square D 8536SBO2V08 Motor Starter 208 VAC 18 Amp 5 Hp 3-Pole Open Type

Product Description

The Square D 8536SBO2V08 is a robust motor starter designed for full voltage control of AC squirrel cage motors. This three-pole, NEMA Size 0 starter offers non-reversing operation with an 18 ampere current capacity. It features a melting alloy type overload relay and a 208 VAC 60 Hz operating coil, suitable for common control setups, ensuring reliable performance in various industrial applications.

• Efficient motor control with a 5 kA Short Circuit Current Rating per UL508A.
• Equipped with type B thermal units for accurate over-current sensing.
• Open type design without an enclosure, making it adaptable for multiple setups.

Product Highlights

Optimized for high-performance, this motor starter is ideal for initiating full-voltage starting and stopping, facilitating up to 5 HP operation at both 460 and 575 VAC. UL listed and CSA certified, it assures compliance with stringent safety standards.

Product Information

Standard Information

• Brand: Square D
• MPN: 8536SBO2V08

Technical Specifications

• Product Type: Motor starter
• Current: 18 Amp
• Voltage: 208 VAC
• Size: NEMA Size 0
• Number of Poles: 3 Pole
• Phase: 3 Phase
• Certifications: CSA, NEMA, UL Listed
• Height: 6.77 inches
• Width: 3.50 inches
• Depth: 4.22 inches
