Schneider Electric LX1FH2002 TeSys F - contactor coil - 200...208 V AC 40...400 Hz

Product Description

The Schneider Electric LX1FH2002 is a TeSys F contactor coil designed for 200 to 208 volts AC at a frequency of 40 to 400 Hertz. It features low sealed consumption, making it suitable for use with TeSys F three-pole and four-pole contactors such as LC1 F265 and LC1 F330. The product operates efficiently within voltage limits ranging from 0.85 to 1.1 times the rated voltage and can handle environments up to fifty-five degrees Celsius.

• Compatible with LC1 F265 and LC1 F330 contactors
• Operates in voltage limits of 0.85-1.1 Uc
• High operating rate of up to 2400 cycles per hour

Product Highlights

This coil is RoHS and REACh compliant, making it environmentally friendly. Its green premium compliance ensures it meets strict environmental standards.

Product Information

Standard Information

• Catalog Number: LX1FH2002
• Manufacturer: Schneider Electric

Technical Specifications

• Coil Voltage: 200...208 V AC 40...400 Hz
• Operating Cycles: 2400 cycles/hour at 131°F (55°C)
• Country of Origin: Czech Republic
• Warranty Length: 18 months
• Net Weight: 0.75 kg
• GTIN: 03389110454222
• Item Type: Contactor coil
