Schneider Electric ATV212HU15M3X Variable Speed Drive 2 Hp 200 to 240 VAC

Product Description

The Schneider Electric ATV212HU15M3X is a variable speed drive designed for managing 3-phase asynchronous motors. It operates efficiently within a voltage range of 200 to 240 VAC and can handle power levels up to 2 Hp. The drive has an IP21 protection rating and features a design focused on energy efficiency, potentially reducing energy consumption by up to 70% compared to traditional systems.

• Suitable for HVAC applications like heating, ventilation, and air conditioning.
• Integrated technologies help reduce cable temperature rise, enhancing performance.
• Supports multiple communication protocols including Modbus and BACnet.

Product Highlights

This drive is optimal for fluid management in tertiary buildings while conforming to various international standards.

Product Information

Standard Information

• Brand: Schneider Electric
• Manufacturer: Square-D / Schneider

Technical Specifications

• MPN: ATV212HU15M3X
• Power Rating: 1.5 kW
• Weight: 1.8 kg
• Dimensions: 107 mm width, 143 mm height, 150 mm depth
• Number of Phases: 3 Phase
• Temperature Range: -25 to 70 degrees C
• Environmental Standards: IEC/EN 61800-5-1, IEC/EN 61800-3
• Certifications: CE, UL, CSA, C-Tick, NOM
