ROMEX ROMEX6/2W/GRD125C Romex Wire NM-B 6/2 Copper w/Ground Non-Metallic Sheathed Branch Circuit Cable (125ft Coil) ROMEX6/2W/GRD125C

Product Description

ROMEX offers the ROMEX6/2W/GRD125C, a Romex Wire NM-B 6/2 Copper with Ground Non-Metallic Sheathed Branch Circuit Cable, ideal for residential electrical wiring. This cable measures one hundred twenty-five feet in length and is suitable for dry locations, compliant with National Electrical Code (NEC) standards. It is used primarily for branch circuits that connect to outlets, switches, and various electrical loads.

• Utilized in both exposed and concealed installations.
• Constructed with annealed copper conductors, ensuring reliable performance.
• Features PVC insulation and a nylon sheath for added protection.

Product Highlights

This cable efficiently transports electrical power in home installations, allowing for safe routing through walls and ceilings as long as conditions are dry.

Product Information

Standard Information

• Conductor Size: 6 AWG
• Number of Conductors: 2

Technical Specifications

• Ground Size: 1x10 AWG
• Voltage Rating: 600 V
• Amperage Rating: 55 A
• Maximum Conductor Temperature: 90°C (194°F)
• Insulation Material: Polyvinyl Chloride (PVC) with Nylon Sheath
• Jacket Material: Polyvinyl Chloride (PVC)
• Conductor Material: Annealed Copper
• Conductor Strands: 7
• Approximate Outer Diameter: 0.700 x 0.314 inches
• Standards: UL 719, Federal Specification A-A-59544, ASTM B3, ASTM B8, RoHS-2
