ROMEX ROMEX12/2-2W/GRD250C Southwire Romex SIMpull 12/2 Solid CU NM-B W/G Wire

Product Description

The ROMEX brand ROMEX12/2-2W/GRD250C is a SIMpull Type NM-B cable designed for residential wiring. This non-metallic sheathed cable is ideal for branch circuits for outlets, switches, and loads. It is suitable for both exposed and concealed installations in dry locations. The cable features solid copper conductors and has a voltage rating of six hundred volts.

• Made with annealed copper conductors and a bare ground wire.
• Eligible for installation in air voids of masonry block or tile walls, provided the walls are dry.
• Jacket color for 12 AWG wire is yellow.

Product Highlights

This cable is built for ease of installation with its unique SIMpull jacket that simplifies pulling. Although the insulation is rated for ninety degrees Celsius, it is important to note that the ampacity is limited to sixty degrees Celsius according to the National Electric Code.

Product Information

Standard Information

• Brand: ROMEX (by Southwire)
• Cable Type: NM-B (Non-Metallic Sheathed)

Technical Specifications

• Wire Gauge: 12 AWG
• Number of Conductors: 2 with ground
• Conductor Material: Copper
• Voltage Rating: 600 V
• Total Wire Length: 250 ft
• Conductor Insulation Material: Polyvinyl Chloride (PVC) with Nylon Sheath
• Jacket Material: Polyvinyl Chloride (PVC) with SIMpull Technology
• Conductor Temperature Rating: 90°C (Ampacity limited to 60°C)
